440V Diesel Standby Generator Emergency Prevention Electric Diesel Generator

one
MOQ
Email reply
Price
440V Diesel Standby Generator Emergency Prevention Electric Diesel Generator
Features Gallery Product Description Request A Quote
Features
Specifications
Style: Base Type Oil Tank
Rated Power: 1000kWe/1250kVA
Rated Frequenc: 60HZ
Rated Speed: 1800rpm
Rated Voltage: 440V
Starting Method: DC24V
Engine Brand: Cummins
High Light:

440V Diesel Standby Generator

,

440V Electric Diesel Generator

,

Emergency Prevention Electric Diesel Generator

Basic Infomation
Place of Origin: Taizhou City,Jiangsu Province,China
Brand Name: Cummins
Certification: ISO9001
Model Number: HD-1000GF
Payment & Shipping Terms
Packaging Details: Rainproof packaging
Delivery Time: 10-25 days
Payment Terms: LC,TTB
Supply Ability: hundred
Product Description


 Rated Power 1000kWe Cummins Diesel Generator Set Base Type Oil Tank Land Power Station


1.  Reliable power quality: The diesel generator set produced by our company uses the world-renowned brand Cummins engine (CUMMINS). Introduction to Cummins Engine: Cummins Engine Company was formally established in the United States in 1919. Cummins is the world's leading manufacturer of power equipment, with a power range of 31~3500 horsepower, widely used in construction machinery, mining machinery, agricultural machinery , ships, oil and gas fields.
2.  Reliable generator quality: The diesel generators produced by our company are equipped with generators with reliable quality and high market holdings, such as  Stamford generator (STAMFORD) Optional Permanent Magnet Generator (PMG) - Offers enhanced motor starting and fault clearing short circuit capability.Alternator - Low reactance 2/3 pitch windings; low waveform distortion with non-linear loads, fault clearing short-circuits capability, and class H insulation.
3.  The control system has high precision: the diesel generator set control system produced by our company uses the LCD screen controller,Such as:  smartgen controller (smartgen)
4.  Wide power coverage: The power of diesel generator sets produced by our company covers 20-1200kWe, which can meet various electricity needs of users.
5.  The overall performance of the unit is reliable: In addition to choosing well-known brand power, brand output generators, and precise controllers, our company also uses well-known brands for other components such as Schneider for circuit breakers and camel for batteries. The quality of the whole machine is reliable, and it is safe and convenient to use.

6.  Cummins heavy-duty engine - Rugged 4-cycle industrial diesel delivers reliable power, low emissions and fast response to load changes.

7.  "Zero" risk commitment: zero links in the middle, the most favorable price

8.  Super high cost performance,Reduce purchase cost by 17.3%.

9.   Free solution before purchasing,customize project solutions for you free of charge

 Gen-set Specifications
Gen-set Model HD-1000GF Rated Frequency 50Hz/60Hz
Rated Power  1000kWe/1250kVA Rated Speed 1500rpm/1800rpm
Standby Power 1100kWe/1375kVA Rated Current 1800A(400V)
Rated Voltage 400/440V Weight 9500kg
Fuel Consumption(Rated) 208g/kW•h

Outline Dimension(L×W×H)

5400×2150×2500mm
 Engine Technical Datasheet
Engine Model KTA50-G12 3Brand CCEC Cummins
Rated Power 1148kW Number of Cylinders 16
Bore×Stroke 159mm×159mm Governor Electronic
Displacement 50Liters Lubricant Capacity 177L
Starting method DC24V
Alternator Technical Datasheet
Alternator Model S6L1D-G41 Brand Stamford
Rated Power  1008kW Protection Grade IP23
Voltage regulation AVR Excitation brushless PMG
Insulation Grade H Type  3phase 4wire
Control system Technical Datasheet

1,Multi-interface display unit work and alarm state, intuitively clear, LCD displays the parameters of diesel engines.

2,Microcomputer can be set on the control panel input, output, alarm, delay and other

3,parameters.Maintenance, manual, automatic and other modes of operation.
Display Data

1,Engine Data: Speed, Oil Pressure, Water Temperature, Battery Volt, Running TimingAlternator

2,Data: Gen-set/Mains Frequency, Gen-set/Mains 3-Phase Volt(L-L,L-N) ,Current, kVA,kW,PF,kVAR,kWh,kVAh,kVARh
Detection and protection function

1,Over / under speed, Low Oil Pressure, High Water Temperature, under Battery Volt,Low water level,Three failed to start alarm

2,Over / under voltage,Over current,Over / under frequency, Over Power, Short circuit
